430XM4
430XM4 — Electric Driven Oil Fired Hot Water Pressure Washer
BUILT FOR SERIOUS OPERATORS.
Alkota 430XM4 is an industrial-grade hot water cleaning system engineered in South Dakota by Alkota and built for the demanding conditions of UK commercial and industrial operators. Delivering 207 bar (3000 PSI) at 13.6 L/min (3.6 GPM), it features Alkota's signature heavy-gauge welded chassis and precision-engineered oil bath crankcase | triplex ceramic plunger.
Built for intensive continuous duty, the Alkota 430XM4 combines high-efficiency heat exchange with industrial-grade mechanical components. Alkota's proprietary coil technology features a hydro-insulated cold-water wrap that protects operators, pre-heats incoming water, and eliminates thermal shock — backed by a 7-year warranty.
Oil Bath Crankcase
Oil-bath crankcase and ceramic plungers running at lower RPM for cooler, vibration-damped longevity.
Vertical Schedule 80 Coil
Hydro-insulated cold water wrap pre-heats water, protects operators, and eliminates thermal coil stress.
7-Year Coil Warranty
The benchmark in industrial heating reliability. Alkota Schedule 80 coils are guaranteed for 7 years.
Welded Steel Chassis
Heavy-gauge welded structural steel frame with powder coat finish built to survive demanding site environments.
Full Technical Specifications
| Operating Pressure | 207 BAR(3000 PSI) |
| Water Flow Rate | 13.6 L/min(3.6 GPM) |
| Max Temperature | 98°C(208°F) |
| Thermal Output | 350,000 BTU/hr(102.6 kW thermal) |
| Electrical Supply | 230 v / 1-Phase / 40A |
| Drive Unit | Electric Motor · 6 kW · (8 HP) |
| Heating Fuel | Kerosene, #1, #2 Diesel |
| Fuel Tank Capacity | 30.3 L(8 gal) |
| Fuel Consumption | 9.5 L/hr(2.5 gal/hr) |
| Operating Weight | 283 kg(625 lbs) |
| Dimensions (L×W×H) | 1168 × 813 × 1245 mm |
| Chassis / Mobility | 4-Wheel Heavy-Duty Pneumatic Chassis |
| Pump Architecture | Oil Bath Crankcase · Triplex Ceramic Plunger |
| Heating Coil System | Vertical Schedule 80 |
| Coil Pipe Length | 38 m(126 ft) |
| Duty Rating | Continuous Industrial Duty (6–10 hrs/day) |
| Certifications | ETL certified to UL-1776 · CSA Certified |
| Coil Warranty | 7 Years (Hydro-Insulated) |
Primary Industrial Use Cases
Standard Engineering Features
Factory-Available Options
Engineering Documentation
Official Alkota Factory Publications
SUPPORTING EQUIPMENT & ACCESSORIES
Every component below is verified against factory schematics, hydraulic output curves, or application guidelines for the Alkota 430XM4.
General Pump TS2021 Triplex Plunger Pump
The benchmark triplex plunger pump used across Alkota heavy-duty hot and cold water pressure washers. Features forged brass manifold, solid ceramic plungers, unitised stainless steel inlet/discharge valves, and heavy die-cast anodised aluminium crankcase.
Alkota USA factory parts manual. 430XM4 utilizes TS2021 high-pressure manifold variant.
Need assistance selecting parts or accessories for model 430XM4?
Our UK engineering team verifies nozzle orifices, unloader ratings, and chemical injection ratios before dispatch to ensure 100% operational compatibility.
Hog Heaven — 2,400-Head Swine Facility Deep Clean
See how extreme industrial cleaning challenges push professional Alkota equipment beyond ordinary pressure washing. The inaugural Mess Quest episode: tackling massive biological muck, encrusted manure, and biosecurity sanitisation across a 2,400-head swine finishing barn.
SPECIFY THE 430XM4.
Connect directly with Alkota UK application engineers to verify flow rates, power supplies, wash bay layouts, or trailer integration. We provide direct factory quotations and technical advice.
