5301
5301 — LP and Natural Gas Hot Water Pressure Washers
BUILT FOR SERIOUS OPERATORS.
Alkota 5301 is an industrial-grade hot water cleaning system engineered in South Dakota by Alkota and built for the demanding conditions of UK commercial and industrial operators. Delivering 207 bar (3000 PSI) at 18.9 L/min (5 GPM), it features Alkota's signature heavy-gauge welded chassis and precision-engineered oil bath crankcase | triplex ceramic plunger.
Built for intensive continuous duty, the Alkota 5301 combines high-efficiency heat exchange with industrial-grade mechanical components. Alkota's proprietary coil technology features a hydro-insulated cold-water wrap that protects operators, pre-heats incoming water, and eliminates thermal shock — backed by a 7-year warranty.
Oil Bath Crankcase
Oil-bath crankcase and ceramic plungers running at lower RPM for cooler, vibration-damped longevity.
Vertical Schedule 80 Coil
Hydro-insulated cold water wrap pre-heats water, protects operators, and eliminates thermal coil stress.
7-Year Coil Warranty
The benchmark in industrial heating reliability. Alkota Schedule 80 coils are guaranteed for 7 years.
Welded Steel Chassis
Heavy-gauge welded structural steel frame with powder coat finish built to survive demanding site environments.
Full Technical Specifications
| Operating Pressure | 207 BAR(3000 PSI) |
| Water Flow Rate | 18.9 L/min(5 GPM) |
| Max Temperature | 98°C(208°F) |
| Thermal Output | 440,000 BTU/hr(129 kW thermal) |
| Electrical Supply | 230 v / 1-Phase / 50A |
| Drive Unit | Electric Motor · 7.5 kW · (10 HP) |
| Heating Fuel | LP or NG |
| Operating Weight | 399 kg(880 lbs) |
| Dimensions (L×W×H) | 1422 × 686 × 1397 mm |
| Chassis / Mobility | 4-Wheel Heavy-Duty Pneumatic Chassis |
| Pump Architecture | Oil Bath Crankcase · Triplex Ceramic Plunger |
| Heating Coil System | Vertical Schedule 80 |
| Coil Pipe Length | 74 m(243 ft) |
| Duty Rating | Continuous Industrial Duty (6–10 hrs/day) |
| Certifications | Approved for UL-60335-1 / UL-60335-2-79 · CSA Certified |
| Coil Warranty | 7 Years (Hydro-Insulated) |
Primary Industrial Use Cases
Standard Engineering Features
Factory-Available Options
Engineering Documentation
Official Alkota Factory Publications
Hog Heaven — 2,400-Head Swine Facility Deep Clean
See how extreme industrial cleaning challenges push professional Alkota equipment beyond ordinary pressure washing. The inaugural Mess Quest episode: tackling massive biological muck, encrusted manure, and biosecurity sanitisation across a 2,400-head swine finishing barn.
SPECIFY THE 5301.
Connect directly with Alkota UK application engineers to verify flow rates, power supplies, wash bay layouts, or trailer integration. We provide direct factory quotations and technical advice.
